Advantages
* Up to 10 dBA noise reduction
* Reduced air consumption
* 30:1 air amplification
* Aluminum or stainless steel
* Compact, rugged, easy to install
* Stock lengths up to 48" 1219 mm
* No moving parts
* Compressed air inlets on each end
* Variable force and flow

**Universal Air Knife Mounting System -** The Model 9060 Universal Air Knife
Mounting System is used to provide secure, precise positioning for any of the
EXAIR Air Knives. The Air Knife can quickly and easily be moved within close
proximity of the part to improve effectiveness. It can be mounted on either
the top or bottom of most Air Knives (Super Air Knife, Standard Air Knife and
Full-Flow Air Knife). The Universal Air Knife Mounting System has a durable,
stainless steel construction that is suitable for a variety of industrial
applications.
The Universal Air Knife Mounting System can be articulated into any position
and provides a maximum extension of 30" 762 . A 1/2" diameter hole is
required for mounting. Alternatively, the bolt can be threaded directly into a
1/2"-13 tapped hole. For any style Air Knife that is 24" 610 to 54"
1372 , use (2) Universal Air Knife Mounting Systems. For knives 55"
(1397 ) - 71" (1803 ), use (3). For 72" 1829 - 95" (2413 ), use (4).
For knives 96" 2438 and over, use (5).
**Air Knife Shim Sets -** Compressed air exhausts through a gap in the Air
Knife which is set with a shim. Force and flow may be increased by adding
shims.
Shim sets for aluminum Standard Air Knives Inclusde a .001" (0.03 ) Amber
color, .003" (0.08 ) Green color, and .004" (0.10 ) thick Tan color plastic
shim . A Red color .002" (0.05 ) thick shim comes installed in the Standard
Air Knife. Shim sets for stainless steel Standard Air Knives Inclusde (3) .002"
(0.05 ) thick stainless steel shims.
