Advantages
* Quiet - 69 dBA for most applications
* Minimal air consumption
* 40:1 air amplification
* Uniform airflow across entire length
* Variable force and flow
* No moving parts - maintenance free
* Easy mounting - compressed air inlets on each end and bottom
* Compact, rugged, easy to install
* Recessed hardware
* Stock lengths to 108" 2743 mm in aluminum, 303 stainless steel, and 316 stainless steel (ss - for temperatures up to 800°F (427°C), food processing or corrosive environments), and PVDF up to 54" 1372 mm for superior corrosion resistance.
* Special lengths available
* Unlimited system lengths of uninterrupted airflow available

**Universal Air Knife Mounting System -** The Model 9060 Universal Air Knife
Mounting System is used to provide secure, precise positioning for any of the
EXAIR Air Knives. The Air Knife can quickly and easily be moved within close
proximity of the part to improve effectiveness. It can be mounted on either
the top or bottom of most Air Knives (Super Air Knife, Standard Air Knife and
Full-Flow Air Knife). The Universal Air Knife Mounting System has a durable,
stainless steel construction that is suitable for a variety of industrial
applications.
The mounting system can also be used with EXAIR Static Eliminators. For the
Super Ion Air Knife, it can be mounted on the top. Bottom mounting is possible
on Super Ion Air Knives that are 18" 457 or longer. For the Standard Ion
Air Knife, it can be top mounted on any length. Bottom mounting is possible on
Standard Ion Air Knives that are 9" 229 or longer.
The Universal Air Knife Mounting System can be articulated into any position
and provides a maximum extension of 30" 762 . A 1/2" diameter hole is
required for mounting. Alternatively, the bolt can be threaded directly into a
1/2"-13 tapped hole. For any style Air Knife that is 24" 610 to 54"
1372 , use (2) Universal Air Knife Mounting Systems. For knives 55"
(1397 ) - 71" (1803 ), use (3). For 72" 1829 - 95" (2413 ), use (4).
For knives 96" 2438 and over, use (5).
**Air Knife Plumbing Kits -** Super Air Knives that are 24" or longer must be
supplied with compressed air at multiple inlets on the knife. The Air Knife
Plumbing Kits prevent you from searching for the right fittings or using
undersized air supply lines. They provide properly sized compressed air hose
or pipe, and fittings to interconnect the bottom or end compressed air inlets
for best performance. Plumbing kits for aluminum Super Air Knives Inclusde a
pressure gauge to monitor pressure at the Super Air Knife, which is an
indication of proper air supply. They also Inclusde nitrile/PVC hose and brass
fittings. Plumbing kits for stainless steel Super Air Knives Inclusde cut to
length type 316 stainless steel pipe and fittings and will also work on PVDF
Super Air Knives.
**Coupling Bracket Kits -** Some applications require a Super Air Knife that
is longer than our 108" 2743 length. Coupling Bracket Kits that join two
Super Air Knives together are available. The kit Inclusdes two rigid plates
along with the assembly screws. The bottom plate is supplied with a hole to
access the bottom compressed air inlets. All models Inclusde stainless steel
screws.
**Air Knife Shim Sets -** Compressed air exhausts through a gap in the Air
Knife which is set with a shim. Force and flow may be increased by adding
shims.
Shim sets for aluminum Super Air Knives Inclusde a .001" (0.03 ) Amber color,
.003" (0.08 ) Green color, and .004" (0.10 ) thick Tan color plastic shim .
A Red color .002" (0.05 ) thick shim comes installed in the Super Air Knife.
Shim sets for stainless steel Super Air Knives Inclusde (3) .002" (0.05 )
thick stainless steel shims. PVDF Super Air Knife shim sets Inclusde (3) .002"
(0.05 ) PTFE shims.
